Chamber Vacuum Sealer in Action with Production Improvement Platform

Watch on YouTube: "Chamber Vacuum Sealer in Action with Production Improvement Platform"

Chamber Sealer Comparison - Vacuum With and Without Gas Flush

Swing Lid Double Chamber in Operation

CHTC-280F Chamber Vacuum Sealer

TECHNICAL SPECIFICATIONS:

Chamber size 14.1" x 15.1"
Chamber depth 2" + 3.7"/145mm
Seal bar length 11.8"/300mm
Vacuum pump capacity 6m3/h (1/2 hp/0.4kw)
Power/Amp 0.6kw/4.4A
Voltage 110V/1PH/60Hz/12A
Machine weight 115 lbs. / 52 kg
Machine size - L x W x H 15" x 18" x 16"
Standard Features:
  • Stainless Steel Construction
  • Clear See through Lid
  • Bladder Activated Sealing
  • PD-01 Digital Control Panel
  • Cut-wire (Contact a sales representative before purchasing to check for cut-wire material compatibility Gramatechsales@ssc.com )






























OPTIONS:

  • Pump Size
  • Voltage
  • Gas Flush
  • Stainless Steel Cart
  • Soft Air
  • Custom Chamber Sizes Available
  • PNC-01 Computerized water-resistant control panel (IP-56, 12 programs with oil indicator)
  • 4mm seal wire


sterile air kit

Sterile Air

Two Pre-filters with PM indicators which remove contaminants and water from the compressed air line before they reach the nitrogen generator. After leaving the generator the air is pushed through a Post filter which results in a Sterile Nitrogen flow of 99.9999+% efficiency at 0.01 micron. This is essential for food and sensitive applications where purity is critical.


nitrogen generator

Nitrogen Generator Kit

The Nitrogen generator produces Nitrogen gas (N2) from a standard compressed air line. This model is designed to generate Nitrogen at purities between 95% and 99.5%.

The Nitrogen generator can be used as a replacement for heavy and bulky Nitrogen gas tanks. Its slick and compact design allows users to integrate this with their current gas flush enabled vacuum sealers without having to worry about it taking up too much space. Also, users will not have to worry about a depleting Nitrogen gas source, as our generator produces Nitrogen from a clean compressed air source.


sterile air kit with nitrogen generator

Sterile Air Kit with Nitrogen Generator



OPTIONS:

  • Pump Size
  • Voltage
  • Gas Flush
  • Stainless Steel Cart
  • Soft Air
  • Custom Chamber Sizes Available
  • PNC-01 Computerized water-resistant control panel (IP-56, 12 programs with oil indicator)
  • 4mm seal wire

NEED POUCHES FOR YOUR VACUUM SEALER? IMPAK recommends the 8.5" x 13.0" O.D. Vacuum Bags

NOTE: This item is also available in PALLET QUANTITIES (Pallet quantity = 38,500 bags)


Contact a sales representative before purchasing to check for cut-wire material compatibility gramatechsales@sorbentsystems.com


The model CHTC-280F may be the smallest of IMPAK's table top chamber vacuum sealers but it is engineered and manufactured to be an industrial quality machine. Both the housing and the vacuum cavity are constructed using all # 304 stainless steel as part of meeting the stringent NSF standards. As with all of the Impak's chamber machines the CHTC-280F also meets UL and CSA safety standards. Meeting the UL, CSA and NSF standards means these machines meet all the requirements for use in restaurants, delis, test kitchens and any other establishment that is inspected by the local or state authorities. The heart of any vacuum chamber machine is the vacuum pump and IMPAK utilizes only Busch vacuum pumps in all models including the CHTC-280F. The CHTC-280F is not only a rugged unit but an easy to operate machine as well. The standard PD-01 control panel allows you to select the vacuum time, gas flush time (if the unit is equipped with the optional gas flush system), seal time and cooling time by simply touching either the up arrow or the down arrow and the digital readout provides total accuracy. If your application can be enhanced by using preset programs, multi-stage gas flush or soft air venting then you can upgrade a CHTC-280F to the PNC-01 microprocessor control panel that allow for all of these features and many more. Learn more about the PD-01 and PNC-01 Microprocessor System.

IMPAK has supplied CHTC-280F machines for the following applications:

  • Sous Vide
  • Pet food packaging
  • Test kitchens
  • Beef jerky packaging
  • Bio test labs ( Non validatable applications)
  • Many more

OPTIONS:

  • Pump Size
  • Voltage
  • Gas Flush
  • Stainless Steel Cart
  • Soft Air
  • Custom Chamber Sizes Available
  • PNC-01 Computerized water-resistant control panel (IP-56, 12 programs with oil indicator)
  • 4mm seal wire

For options, please contact sales@sorbentsystems.com

CHTC-280F: Chamber Vacuum Sealer

  • $2,505.00


Available Options
